200mw High End VCSEL MKII DLD-EG NGAL

200mW High End VCSEL MKII DLD-EG NGAL

Introducing the long-awaited highest end version of the DLD-EG NGAL with a 200mw VCSEL illuminator (realistically 100mW – 120mW).

Each unit is fully hand-sealed by DLD and available in either IP64 or IP67 ratings:

• IP64 Version: Sealed with standard epoxy—ideal for heavy rain and splashes.

• IP67 Version: Sealed with the same gray epoxy used in real units and our fully hand-assembled models — waterproof 1 foot, 5min.

Each NGAL comes with our in-house designed DLD Illuminator Diffuser Cap, allowing users to quickly switch to a wide flood beam for CQB work. As an upgrade, we also offer a functional ND filter, which reduces beam intensity for improved eye safety and less bloom. This ND filter can also be purchased separately to upgrade older models—available here.

As with every DarkLight Dynamics product, we personally hand-inspect each NGAL to ensure it meets my strict quality standards. This rigorous process guarantees that you won’t receive a DOA (Dead on Arrival) unit or anything that falls short of excellence.

Every NGAL order includes a DLD QC Checklist, outlining our thorough quality control process so you can be confident you’re receiving the best possible unit.

Most questions are answered on our FAQ page.

---

New 200MW MKII DLD-EG NGAL Updates

• • New VCSEL Illuminator

  • 150mrad divergence adjustment

  • Better Laser Coalignment (1 MOA)

  • Brighter VIS Laser

  • New Battery Cap Tan anodizing

  • 1 Year Warranty

  • LA23 Plug

  • Functional DLD Illuminator Diffuser Cap

  • IP64 Water Resistance or IP67 Waterproof

---

Includes

• 200MW MKII DLD-EG NGAL

• 1 Year Warranty

• LA23 remote pressure pad

• Warning Stickers

• 3M adhesive strip for pressure pad

• Functional DLD Illuminator Diffuser Cap

• Signed DLD QC Checklist To Each Order

200mW VCSEL MKII DLD-EG NGAL – Specifications

---

Build & Design

• Housing: Forged 6061 aluminum

• Potting: Full PCB Potting

• Adjustments: Clicking windage/elevation adjust

• Finish: Ceramic paint surface finish

• Mount Type: Picatinny mount

• Mounting Torque Specification: 40 in-lbs

• Color: Dark Earth

• Dimensions: 3.54in x 1.96in x 1.37in

• Weight: 5.3 Ounces

• Waterproof Rating: IP64 (Heavy splash & rain) IP67 (Waterproof 1 foot, 5min)

• Zero Retention: Guaranteed to hold zero 5.56 & 1000G

---

Functionality

• Override Function: Visible override function with LA23 plug version

• Illuminator: Adjustable IR illuminator

• Diffuser Cap: Comes with a functional IR illuminator diffuser cap

• Switch Compatibility: Compatible with LA23 switches

---

Laser Specifications

• Co-Alignment Precision: ≤1MOA

IR Laser

• Wavelength: 850nm

• Power (High): 40mW

• Power (Low): 0.6mW

• Beam Divergence: 0.5mrad

Visible Laser

• Wavelengths: 650nm / 520nm

• Power (High): 40mW (Green & red)

• Power (Low): 4.5mW

• Beam Divergence: 0.5mrad

---

IR Illuminator

• Type: VCSEL 830nm

• Power: 200mW (100mW-120mW real world)

• Adjustable Divergence: 15–150mrad

---

Power & Warranty

• Battery Type: 3V CR123A

• Warranty: One year warranty

• Manufacturer: DLD-EG

---
